S&B Tanks 62 Gallon Replacement Fuel Tank - 2011-2023 GM Duramax 6.6L, Crew Cab Short Bed

Thoroughbred Sku #: SBT10-1017
Manufacturer Sku #: 10-1017

Item Options:

Prop 65:
WARNING: Cancer & Reproductive Harm - P65Warnings.ca.gov


$1,249.00

free-shipping-no-handling

Applications:

View All applications

VERIFY VEHICLE FIT

Product Details

Product Name: S&B Tanks 62 Gallon Replacement Fuel Tank
Manufacturer: S&B
Manufacturer Part #: 10-1017
Thoroughbred Diesel Part #: SBT10-1017
Fitment Notes: 2011-2023 GM Duramax 6.6L, Crew Cab Short Bed

Do you have an Auxiliary Fuel Tank? Read why using these with our tanks will void the Lifetime Warranty.

Your fuel gauge will continue to work normally. Unfortunately there is no way to calibrate the distance to empty readout when a larger fuel tank is used on GM trucks. Because the bottom of the S&B tank has a greater surface area, there will be a greater fuel reserve when the low fuel indicator comes on.

Note: GM trucks monitor for an inoperative fuel gauge. When the truck thinks there is a problem it will drop the gauge to empty to get the driver’s attention. High capacity fuel tanks may cause the truck to think there is a problem because the fuel level sensor float arm moves slower than stock. If this happens, the gauge will return to its normal position after restarting the engine.

More Fuel. Less Hassle.

Holds 5 more gallons than competitor tanks!

S&B's 62-gallon fuel tank directly replaces the OEM 36-gallon tank without any cutting, drilling, or special modifications. This makes for a trouble-free, faster installation process. S&B's replacement fuel tank holds 5 more gallons than competitor tanks allowing you to save time, go futher, and get more out of your truck! Go big or go home!

INNOVATIVE BAFFLED DESIGN.

S&B Tanks were engineered with a built-in baffled design. This helps to minimize fuel sloshing. This helps to contain fuel around the fuel pick up and prevents unwanted tank sloshing noise.

DRAIN PLUG EQUIPPED.

Accidents happen, but that doesn't mean you can't be ready for them. This tank features an integrated drain plug that can be drilled out and resealed, just in case gas or diesel exhaust fluid (DEF) is accidentally added into the tank.

LOCKED IN FOR A TRUE SEAL.

The S&B Fuel Tank was designed to use the OEM locking ring. This ensures a perfect seal and securely retains the fuel pump onto the tank.

BUILT TO LAST.

S&B Tanks are made out of an extremely strong crosslink polyethylene and backed by our lifetime warranty.

WARNING For Those Using Auxiliary Fuel Tanks

On S&B and OEM diesel fuel tanks, there are one or more rollover valves. The rollover valve uses a float/weight to close the valve when the float is immersed in fuel. This prevents fuel leakage in the event of a rollover. Gravity feed tanks or electronically controlled feed tanks can overfill the S&B or OEM tank. If/when the tank is overfilled, the rollover valves will prematurely close. Without the required vapor space in the tank, this violates the “overfill restriction” requirement of 49 CFR 393.76(12)(i). An overfilled tank can lead to a pressurized fuel tank, leaking, and tank failure.

Therefore, the use of a gravity feed tank or electronically controlled transfer tanks (that allow the S&B tank to overfill) in conjunction with a S&B Tank is dangerous and will void the S&B Tank warranty.

S&B Tanks 62 Gallon Replacement Fuel Tank Features:

  • 62-gallon fuel tank
  • Directly replaces the OEM 36-gallon tank without any cutting
  • Built-in baffled design
  • Integrated drain plug that can be drilled out and resealed
  • Designed to use the OEM locking ring
  • Made out of an extremely strong crosslink polyethylene
  • Backed by lifetime warranty
  • For more information on S&B call us at 1-859-737-4966
Tank Type Midship
S&B Capacity (Approximate) 62 gallons
OEM Capacity 29 Gallons
Weight (Dry) 45lbs
Ground Clearance Compare to OE Tank 3.5" lower
Sump No
Drain Yes
Sending Unit OE
Straps Included Yes
Compatible with OE Skid Plate No
Compatible with Gooseneck and 5th Wheel Yes
Transfer Pump Ready Yes
Embedded Fitting Thread Size 1/2" NPT

Reviews

  • i have a 2015 gmc 2500hd i installed a lift pump air dog 165 4g on the bracket that sits in front of the oem tank do i need to move the pump to fit this 62gallon tank or will it fir the same way as the original without disturbing the lift pump

    Anibal de jesus nunez | 4/14/2022

    Install should not affect the AirDog location.

  • Do you make a tank the will work for an 08 f350 with the v10?

    Wes Monroe | 8/8/2023

    No diesel tanks only at this time.

  • Does this replacement tank have Accommodations for DEF tank?

    Chad | 12/12/2022

    No modifications needed for the DEF tank.

  • I have a 2004 Dodge Ram 2500 S.A.D. do you make a Right Hand Auxiliary tank to increase diesel volume i have a camper shell and no way for in bed tank to be able to refuel.

  • That did not answer my question. Didn't say if it will or won't. Same bed same stock tank as the crew cab as does the mega cab short bed. So will this tank work or have other options that are not a titan tank. I need this tank Bc the sump on it and putting a lift pump on my truck.

    Andrew | 3/6/2020

    No it wont fit. The 10-1005 is specific to the 2500 Dodge Crew Cab Shortbed trucks, S&B Tanks will be releasing late next month a tank for all the Mega Cab applications which is still in R&D at this time.

  • I have a 2014 ram 2500 mega cab. Will the 52 gallon Tanaka still work on my truck since it is a short bed?

    Andrew | 3/5/2020

    2013-20 Ram Cummins 6.7L, Crew Cab Short Bed (6’ 4”).

  • My 2019 Dodge Ram 3500 short bed (not a dually) only has a 32 gal. tank. I do not want an in bed tank. Do you make a larger capacity stock tank replacement?

    Gary Weed | 9/26/2019

    52 Gallon Replacement Tank For 2013-19 Ram Cummins 6.7L, Crew Cab Short Bed
